System hotel automatic commercial security door lock wifi gate locks

System logic: Anti conflict mechanism.

Method of reading card: Non-contact sensor card.

Read and write features: Readable; writeable, can be encrypted.

Technical specifications: Adopting TI chips from American Texas Instruments.

Production technology: Embedded electronic module and induction coil on PVC surface.

Low voltage indication: When the voltage is lower than 4.8V, still can unlock more than 200 times(afected by the inconsistency of the battery)

Reading time: Swipe card open the door once effective, or do not push handle after swiping card, automatically be locked in 7 seconds.

Unlocking record: Save the latest unlocking records 1000 pcs, including mechanical key unlocking records.


  • 1 - 49 Sets: $30.9
  • 50 - 199 Sets: $29.9
  • 200 - 499 Sets: $28.9
  • 200 - 499 Sets: $27.9
  • Product Detail

    FAQ

    Parameter

    1 Product name  RX2017E
    2 Unlocking way Crad, Mechanical Key
    3 Storage capacity 32 bytes
    4 Card type Temic card / Mifare card
    5 Operating Voltage 6.0V (4 ocs of AA alkaline batteries)
    6 Static power consumption <30uA
    7 Dynamic power consumption 200 mA
    8 Battery life >10000 times
    9 Hotel lock System Compositon Support
    10 Door thickness require 35-55mm (Pls inform if special requests)

    Detail Drawing

    Our Advantages


  • Previous:
  • Next:

  • Q: Are you manufacturer or trading company?

    A: We are a manufacturer in Shenzhen,Guangdong, China expertised in smart lock for over 18 years.

    Q: What kinds of chips can you provide?

    A: ID/EM chips, TEMIC chips (T5557/67/77), Mifare one chips, M1/ID chips.

    Q: What is the lead time?

    A: For sample lock, the lead time is about 3~5 working days.

    For our existing locks, we could produce about 30,000 pieces/month;

    For your customized ones, it depands on your quantity.

    Q: Is customized available?

    A: Yes. The locks can be customized and we could meet your very single request.

    Q: What kind of transportation will you choose to dilivery the goods?

    A: We support various transportation like post, express, by air or by sea.
